BTR-80N narrow band two-channel UHF wireless intercoms
Like the BTR-800, the narrow-band BTR-80N offers two channels of full-duplex audio and has enhanced frequency band options and adds other new innovative features, all with an unprecedented 25 kHz of modulated bandwidth. The BTR-80N allows more users per channel in the cramped UHF spectrum.
Models
 |
 |
 | |
BTR-80N |
TR-80N |
TR-82N | |
| Frequency Band of Operation | 482 – 698 MHz (TV 16 to TV 36 and TV 38 to TV 52) | ||
| Transmit Power | Selectable: (BTR-80N: 249 mW - 10 mW, TR- 80N/TR-82N: 100 mW – 5 mW) | ||
| Power Requirements | 100-240 VAC, 50-60 Hz ; 12-15 Volts DC | 6 “AA” Cells, Alkaline (NiMH optional) | 6 “AA” Cells, Alkaline (NiMH optional) |
| Wireless Technology | UHF | ||
| Operating Temperature | -20 °C - 55°C | -20°C - 55°C | -20°C - 55°C |
| Form Factor | Rackmount | Beltpack | Beltpack |
| Function | User Station | User Station | |
| Binaural | No | Yes | |
| Learn More | Learn More | Learn More |
Show more specs
