Intercom Systems – RTS
The RVON-1 provides a single RJ-45 Ethernet connection for use with a 10 BASE-T or 100 BASE-TX network.
The RVON-1 card supports one channel in and out and has configurable network and bandwidth parameters that can be tailored to individual network functions.
The RVON-1 card uses standard Ethernet protocols and is compatible with 10 BASE-T and 100 BASE-TX Ethernet compliant devices and networks.
Users have the ability to adjust the audio parameters of the RVON-1 channel to optimize the available bandwidth.
When connected to an Ethernet LAN, audio comes from the RVON 1 card; and, when an Ethernet link is not present, the audio comes from the AIO connection.
Installed directly into KP-32 Classic, the RVON-1 provides Voice over IP (Internet Protocol) communications for the RTS intercom family. The RVON-1 delivers an integrated solution for connecting keypanels to the intercom matrix over standard IP networks. The RVON-1 is not compatible with KP 32 CLD series keypanels.
Downloads
| Name | Language & Download |
|---|---|
| RVON-1 Technical Data Sheet | en |
| Name | Language & Download |
|---|---|
| VoIP System Interconnect Diagram CAD Drawing | Download |
| Name | Language & Download |
|---|---|
| RTS Product Catalog 2024 | Download |
