MCP-90-12
12" gooseneck microphone
The MCP-90 series microphones are phantom-powered "back-electret" miniature condenser gooseneck microphones. The back-electret feature provides greater sensitivity, wider frequency response, and superior immunity from handling noise than a diaphragm-electret microphone. The removable windscreen provides pop filtering; response shaping and overload protection to further enhance the acoustic performance of the microphone. The MCP-90 series microphones are mechanically designed for quick, easy mounting to RTS keypanels and selected Audiocom intercoms. The frequency response is tailored for full-range sound reproduction with natural sound pick-up optimized for close-up use. The microphones are fitted with a threaded TRS male connector that is compatible with RTS standard threaded TRS female connectors. The MCP-90 series is designed to be phantom powered with a wide voltage range of 1.5 to 9 VDC.
Specifications
| Length | 304.8 |
| Head Diameter | 14 |
| Neck Diameter | 6.4 |
Downloads
Technical Documentations
| Name | Language & Download |
|---|---|
| MCP-90 Technical Data Sheet | EN |
| Name | Language & Download |
|---|---|
| Asia/Pacific Service Policies | EN |
Marketing Materials
| Name | Language & Download |
|---|---|
| RTS Product Catalog 2024 | Download |
Let's talk
RTS and our certified partners are ready to help support you through planning, purchase, and setup. Services available through our network of highly-qualified associates and partners may include:
- System Design
- Installation
- Programming & Commissioning
Warranty & After Sales Programs
Compatible Products
