DKP-3016 / DKP-3016W
Desktop/wall-mount, 16 keys
- Backward compatible with older technologies such as analog audio in USOC and 568-B connector formats.
- Comes with 4 and 5-pin female XLR connectors, analog matrix connection, and RJ45 connector for OMNEO.
- Talk/listen lever keys. Volume may be adjusted with the volume control knob.
- New wide-angle high-definition display.
- Enhanced navigation menus optimized for ease of use.
Specifications
| LCD Display | |
| Active Area | 120.10 mm (wide) x 35.86 mm (high) |
| Dot Resolution | 576 x 172 pixels |
| Color Resolution | 16-bit (64K)RGB color |
| View Angle | 80 degrees (typical; all directions) |
| Power Supply | |
| Type | Internal |
| AC Input | 100–240VAC 50/60Hz |
Specifications | |
| Inputs | |
| Matrix | |
| Type | Balanced |
| Typical Input Level | +8dBu |
| Typical Input Impedance | >10kΩ |
| Maximum Input Level | +20dBu |
| Supported Bandwidth | 100Hz to 20KHz |
| Panel Mic | |
| Type | Electret |
| Typical Input Level | -42dBu |
| Typical Input Impedance | 1kΩ |
| Maximum Input Level | -25dBu |
| Left and Right Headset Mic - Electret | |
| Typical Input Level | -42dBu |
| Typical Input Impedance | 1kΩ |
| Maximum Input Level | -25dBu |
| Left and Right Headset Mic - Dynamic | |
| Typical Input Level | -50dBu |
| Typical Input Impedance | 600Ω |
| Maximum Input Level | -25dBu |
| Outputs | |
| Matrix | |
| Type | Balanced |
| Typical Output Level | +8dBu |
| THD+N% | <0.20% |
| Typical Output Impedance | 600Ω |
| Maximum Output Level | +20dBu |
| Frequency Response | 100Hz to 20KHz |
| Headset - Left & Right | |
| Maximum | |
| Output Power | 125mW for 32Ω load |
| Earphone Impedance | 16Ω and above |
| THD+N% | <0.20% |
| Frequency Response | 20Hz to 20KHz |
| Digital | |
| OMNEO Channels | |
| Typical OMNEO Latency | 1ms |
| Frequency Response | 20Hz - 20KHz |
| Environmental | |
| Dimensions | 3.60 in. H x 10.63 in. W x 9.35 in. D (91.5 mm H x 270.1 mm W x 237.6 mm D) |
| Weight | |
| Weight | 3.59lb (1.63kg) |
| Temperature | |
| Operating | 32°F to 122°F (0°C to 50°C) |
| Storage | -4°F to 158°F (-20°C to 70°C) |
| Power Consumption | |
| Nominal | 13 Watts |
| Maximum | 17 Watts |
| Maximum Volt Amp | 42 VA |
| Certification | CE Compliance UL Certified |
